Greenwich Playhouse - Equipment List

Lighting -
Lanterns
2x Strand Patt 23 (650w) c/w gate and shutters
1x Strand Patt 23 (650w) w/o gate
8x Strand Patt 123 (650w) c/w barndoors
2x Strand Quartet 22/40 (650w) zoom profile
3x Strand Quartet 25 (650w) profile
2x Strand Quartet Fresnels (650w)
4x 240v 'Birdies' 50/75w
2x 12v 'Birdies' c/w dimmable transformers
2x 500w 'Sun' Floods
12x ‘Grelco’ 15A 2-way splitters

Control
Zero88 ‘Alcora’ 12/24 Lighting Desk
( 24 channel / 99 memory or 24-way, 2-preset manual desk with simultaneous analogue and DMX512 output via std 5-pin DIN)

Dimming
18x 10A / 2.3kW Dimmers
(Controlled via three, 8-pin DIN, Zero88 pin-outs)

The House dimmers are controlled from the analogue outputs from the desk.

House Lights controlled separately

Power
3x 60A Single phase outlets with 63A single phase connectors for lighting
1x 13A isolated clean supply for sound

Sound
1x Yamaha 14/2 mixer with 6 band eq.
( 6x Mic or Line input, 4x Stereo Line inputs )
1x Sony MiniDisc recorder with auto-pause
1x Technics CD player with track programming
2x Bose 302 speakers for FOH
1x Stereo Power amp for FOH

Show relay / FX feed via aux’s on sound desk to both dressing rooms

For further enquiries please contact:

The Artistic Director, Alice de Sousa,
Greenwich Playhouse, Greenwich Station Forecourt,
189 Greenwich High Road,
LONDON SE10 8JA.
Tel: 020 8858 9256
E-mail: boxoffice@galleontheatre.co.uk
